Wood Router 2030 Cnc Machine Cnc Woodworking Machinery

SESAME Series CNC router is constructed with heavy-duty thickened bed made from welded 200*300mm square tube, side hanging structure, cast iron column and 150*200mm gantry. Be equipped with CNC machining center finishing precision aviation aluminum head parts.
Working Area:
Cooling Mode:
Driving System:
Spindle Motor:
Dust collector:
Availability:
  • SESAME S2

  • UTECH

Wood Router 2030 Cnc Machine Cnc Woodworking Machinery

lADPDh0cPtQV98bNAorNB4A_1920_650

SESAME Series CNC milling machines feature a heavy-duty thickened bed welded with 200*300mm square tubes, side hanging structure, cast iron column and 150*200mm gantry frame. Equipped with CNC machining center to finish precision aviation aluminum head parts.

SESAME series CNC milling machine adopts reducer structure. Compared with the characteristics of loose gear box and synchronous belt, short life and no obvious deceleration effect, SESAME series CNC milling machine has the advantages of small backlash, low noise, high strength and accurate deceleration. Impact.

SESAME series CNC routers are assembled by the precision instruments of the professional assembly team of Youte, ensuring the accuracy of repeated positioning ±0.01mm and the accuracy of returning to the mechanical origin ±0.02mm.

SESAME series CNC routers use industrial-quality, high-precision linear guides to provide less rolling torque resistance and greater motor torque. And with dust cover, reduce friction, prolong service life.

配件

Patent separable structure

The SESAME CNC's legs and body can be separated freely, saving packaging volume and shipping costs.

l If you are individual buyer: 2 sets /3 sets can be packed in wooden cases

l If you are a dealer

One 40'HQ container can pack 14 sets of SESAME 1325.

A 20'GP container that packs 6 sets of SESAME 1325.

Easy to install the disassembly method and installation guide video, so that you have no worries at home.

lADPDiCpvXiBp6jNAorNB4A_1920_650

lALPDhmOwC7umo_NAorNB4A_1920_650



Descriptions

Parameters

Model

SESAME S2 1325

SESAME S2 1530

SESAME S2 2030

SESAME S2 2040

Working area

1300*2500mm

1500*3000mm

2000*3000mm

2000*4000mm

Accuracy

0.05mm

Table Surface

 Vacuum&T-slot table

Frame

Square pipe welding bed structure 200*300mm+150*200mmgantry

X, Y Structure

1.25M Gear and rack transmission, Taiwan Linear Rail

Z Structure

Taiwan TBI Ball Screw, Taiwan Linear Rail

Spindle Power

4.5kw air cooled spindle+ER25 cutter

Spindle Speed

0-24000RPM

Drive Motors

JMC stepper motor and driver

Working Voltage

AC 220/380V

Command Language

G Code

Operating System

HD100 handle controller (DSP or Mach3 optional)

Computer Interface

Ethernet (or USB)

Inverter

Best

Software

Vectric Aspire/Type 3 /Artcam /Ucancam/JDPaint


Signage and advertising (indoor and outdoor signage, carvings and bas-reliefs, 3D letters, funerals)

Relief and 3D carving and cylinder projects.

Plastics and composites (ACP, ACM, solid surface materials, etc.)

Nonferrous metals and oceans

Applied materials

Wood: Plywood, cork, hardwood, MDF, Particleboard

Plastics: acrylic, ABS, HDPE, PVC, UHMW, HDPE

Stone: granite, marble, SLATE, basalt, cobblestone, natural stone, ceramics, porcelain

Soft metals: Aluminum, brass, copper, mild steel

Composite material: aluminum composite material, copper composite material, titanium composite material, zinc composite material.

lADPDhJzwzQI7NTNAorNB4A_1920_650


Packing:
1/ If the machine is delivered via LCL, then would be packed with wrapping film, EPE foam, and a standard export plywood box.
2/ If machine delivery via FCL, then don't need a wood box, would be packed with wrapping film and EPE foam.

Shipping:
We support machine delivery via express, air transportation, land transportation, and sea transportation.
1/ Such as some small machine, Mini CNC Router or Small CO2 Laser Machine and Fiber Laser Marking Machine, usually delivered via
express and air transportation.
2/ If you wanna us to help you deliver to a domestic warehouse or Russia, Kazakhstan, etc, usually delivered via land transportation.
3/ Large machines or some countries where shipping is more convenient, usually suggest choosing sea transportation.
You can choose any way you'd prefer, we also will give you some proper suggestions.
