On Sale Industrial Plasma Cutting Machine for Metal

cnc water table plasma cutting machine 1200x2500 mm CNC Plasma Cutting Machine 12mm Thickness Metal Sheet Plasma Cutter.

Rated Power:	8.5KW
Plasma power:	63A/100A/160A/200A
Cutting thickness:	0-30mm
Worktable:	Blade Worktable or Swatooth
Transmission:	Rack Gear Transmission
Availability:



Inquire Add to Basket

Model:
Sesame
Brand:
UTECH
Code:
UT-1325P

Product Description

SESAME Plasma Cutting Machine with Water Table for Thick Metal Cutting

There are some questions i want to confirm with you.

1. How about the machine size you need? The hot sell type is 1325, 1530.

2. How about the plasma power you need? if you're not sure, also could tell me your material and cutting thickness.

3. Do you have 380V three-phase voltage?

Characteristics:

(1) Welded thick-walled steel structure, after special treatment, no distortion for the whole structure high precision, and longservice life time.
(2) Cutting system use Beijing Starfire system/ Start system/ FLMC-2300A or DSP system; Equipped with automatic height controller (THC controller), which can according to your material planeness, cutting head can automatically stable, and fast adjust.
(3) Taiwan HIWIN linear rail, ensure vertical section, more precision.
(4) Suitable software: Artcam/ Fastcam/ Starfire etc.
(5) FASTCAM programming software based on AutoCAD automatic programming and material system.
(6) FASTCAM is designed for all kinds of NC cutter with cutting software, the software can help the user completing various complex parts drawing, programming, material, using convenient, also bring the obvious economic benefit.
(7) If you cut thick material, according to actual use, we’ll add water tank for you for free, to absorbs a large amount of smoke generated during cutting.

(8) Machine could be customized, whatever specifications, appearance, etc. Any request you’ve, could tell us directly.

Brand	Power	Recommended cutting thickness for carbon steel	Recommended cutting thickness for stainless steel
	LGK 63A	10mm	5mm
	LGK 100A	12mm	6mm
	LGK 120A	15mm	8mm
	LGK 160A	20mm	10mm
	LGK 200A	25mm	15mm
	Powermax 45A	8mm	3mm
	Powermax 65A	12mm	5mm
	Powermax 85A	15mm	6mm
	Powermax 105A	18mm	10mm
	Powermax 125A	25mm	16mm

Details:

Model	UT-1325P CNC Plasma cutting machine (Other models are optional)
Working size	1300x2500mm (4x8ft) (Other working sizes are optional)
Three axes repeat positioning accuracy	±0.05mm
Process precision	±0.35mm
Transmission system	X, Y: Taiwan Hiwin high-precision, zero clearance increased linear guide+ rack Z: the arc voltage control
Max. cutting speed	15000mm/min
Working voltage	AC220/50HZ
Working voltage	Starfire plasma cutting system Standard high sensitivity arc voltage device
Software support	FASTCAM,AutoCAD,etc
Instruction format	G code
Drive system	Stepper motor
Plasma power supply	Huayuan 63A/120A/160A/200A. Optional, USA Hypertherm, 45A/65A/85A/105A/125A

Advantages:

1. Plasma power	Hypertherm 200A power Famous brand all of the world, low price, Cutting thickness 0.3-52mm
2. Controller system	Beijing Start control system, configured 7-inch high-resolution true color LCD display. can be dynamically cut graphics running track.
3. Motor	450B stepper motors With high quality & stronger power, ensure machine work very well.
4. Driver	Leadshine 860H Drivers It can run with smaller noise, lower heating, smoother movement and have better performances at higher speed.Save human strength and save time.
5. Automatic Arc Pressure adjustable	Beijing Start Adjust the torch height during cutting. Perforated height self-positioning
6. software	Fast Cam nesting software for machine. Using it, and finally export G code, then can be recognized by machine

Nowadays, the traditional peak season for shipping, coupled with multiple adverse factors such as difficult bookings, serious port congestion, and unstable shipping schedules, has made shipping conditions increasingly tense. SESAME series equipment will give you unexpected surprises.

Packing:

1/ If machine delivery via LCL, then would packed with wrapping film, EPE foam, and standard export plywood box.
2/ If machine delivery via FCL, then dont need wood box, would packed with warpping film and EPE foam.

Shipping:

We support machine delivery via express, air transportation, land transportation and sea transportation.
1/ Such as some small machine, Mini CNC Router or Small CO2 Laser Machine and Fiber Laser Marking Machine, usually delivery via
express and air transportation.
2/ If you wanna us help you delivery to domestic warehouse or Russia, Kazakhstan etc, usually delivery via land transportation.
3/ Large machine or some countries where shipping is more convenient, usually suggest choose sea transportation.
You can choose any way you'd prefer, we also will give you some proper suggestions.
