Kitchen Cabinet Manufacturing Process Cnc 3d Wood Carving Machine Price

SESAME Series CNC router is equipped with reducer structure, compared with the characteristics of the looseness, short life and insignificant deceleration effect of the gear box and timing belt, the reducer has the advantages of low backlash, low noise, high strength, and accurate deceleration effect.
Structure:
Working Table:
Spindle:
Availability:
Kitchen Cabinet Manufacturing Process Cnc 3d Wood Carving Machine Price
Kitchen Cabinet Manufacturing Process Cnc 3d Wood Carving Machine Price
Kitchen Cabinet Manufacturing Process Cnc 3d Wood Carving Machine Price
Kitchen Cabinet Manufacturing Process Cnc 3d Wood Carving Machine Price
Kitchen Cabinet Manufacturing Process Cnc 3d Wood Carving Machine Price
Kitchen Cabinet Manufacturing Process Cnc 3d Wood Carving Machine Price
  • UT-1325

  • UTECH

Your Ideal Choice---UTECH SESAME CNC



The SESAME CNC Router is a cost-effective and feature-rich CNC Router that opens many avenues for your business.

  • Heavy-duty thickened bed made from welded 200*300mm square tube

  • Side hanging structure

  • Heavy-duty mechanical tool column

  • 150*200mm gantry

  • Industrial quality linear bearings

  • Patent type reducer structure

  • 4.5kw air cooled spindle+ER25 collect

  • HD100 handle controller, easy operate

  • The repeat positioning accuracy is ±0.01mm

  • The accuracy of returning to the machine origin is ±0.02mm

  • Aluminum alloy T-shaped table+Vacuum adsorption table

  • Split structure of machine legs and lathe bed

  • Industrial dust removal system


cnc router with vacuum table


SESAME Series CNC Router Machine's Advantages


The SESAME CNC Router’s greatest advantage is machine lathe bed and legs could be split freely, according to the customer’s request, can choose to disassemble the machine when shipping, which could save space and shipping cost. In such a severe international situation, harsh conditions such as difficulty in booking space and rising freight rates have severely hindered the transportation of goods and the normal operation and development of enterprises. SESAME’s disassembly advantage would be a shining point in the near future. The UTECH team has tested and implemented many loading and unloading solutions, such as 2/3 machines to pack the same wooden box; a 20GP container to package 6 sets SESAME 1325, a 40HQ container to package 20 sets SESAME 1325, etc.

Before the machine leaves the factory, each machine will undergo rigorous testing. You can leave the factory only after reaching the standard, and you will get a perfect device that can be used directly. And we provide local services, such as the United States, Mexico, Peru, France, Spain, Romania, and other countries.


CNC--


Product Parameter


Working area
1300*2500mm, 1500*3000mm, 2000*3000mm, etc. support customized.
Control syetem
Handle controller, HD100 or RichAuto DSP; Nc-stuido, Mach3, etc.
Table surface
Vacuum table, T-slot table, roller, etc.
Machine frame
Square pipe welding bed structure 200*300mm+150*200mm gantry
X, Y Structure 1.25M Helical gear rack transmission, Taiwan Linear Rail Guide
Z Structure
Taiwan TBI Ball Screw, Taiwan Linear Rail Guide
Spindle Power 4.5kw air cooled spindle+ER25 cutter
Spindle Speed 18000-24000RPM
Drive Motors Stepper motor and driver+UTECH patent typre reducer
Software
Vectric Aspire/Type 3 /Artcam /Ucancam/JDPaint


Machine Detailed Pictures


Body Structure

Is constructed with the heavy-duty thickened bed made from welded 200*300mm square tube, aside from hanging structure, a cast iron column, and a 150*200mm gantry.


cnc router machine 1325


Machine Spindle

Equipped with 4.5kw air cooled spindle, use ER25 collect, can use 3.175, 4, 6, 8, 12.7, 16mm cutter, sufficient power 3.7kw, much suitable for simple woodworking industry.


Reducer Structure

Is equipped with a reducer structure, compared with the characteristics of the looseness, short life, and insignificant deceleration effect of the gearbox and timing belt, the reducer has the advantages of low backlash, low noise, high strength, and accurate deceleration effect.

woodworking cnc cutting machine


Z axis Structure

Z-axis transmission parts adopt aviation aluminum alloy T6061/6063, which are all made by professional precision machining centers, with high precision.


Patent separable structure

The legs and body of SESAME CNC can be separated freely, save packing volume and shipping cost.

  1. If you are an individual buyer: 2 sets/3 sets can be packed in a wooden box

  2. If you're a dealer

  • a 20GP container to package 6 sets SESAME 1325.

  • a 40HQ container to package 20 sets SESAME 1325.

Easy to install the disassembly method and installation guide video so that you have no worries at home.

plywood cnc cutting machine


Position Forklift

Forklift loading and unloading reserved, which can better protect machine body and cargo's carrying capacity.


Machine Working Table

Vacuum table&T-slot table together, you can choose to use one of them according to which kind of material or size you wanna process. Updated structure, except standard diversion trench, with some drainage groove, increased airflow space, enhanced adsorption.


wood furniture cnc router machine

Applications


1. Advertising industry
Acrylic cutting, density board cutting, snowflake cutting, double color board carving, various advertising boards.
2. Furniture industry
Cabinet doors, wooden doors, solid wood, mahogany furniture, antique furniture, all kinds of composite sheet
cutting carving.
3. Plate processing industry
Insulation board, plastic workpiece, PCB board, anti-double board, epoxy resin, ABS, PP, PE, and other carbon mixtures.
4. Crafts industry
Artificial marble, PVC, wood, plexiglass, copper aluminum, and so on.

atc appilication


FAQ


Which kind of CNC Router is right for me?



Deciding which CNC router to buy depends on what you want to use it for. The materials, application industry, dimensions, thickness, shape, precision, speed, etc that you requested will aid you in choosing the right CNC router.

Whether the equipment needs to be updated in the future or whether the budget is limited affects the choice of equipment.

UTECH has a professional design and technical team, and all specifications and sizes support customization. For a quick quote and get the right machine, these details you need to consider.
