Industrial quality linear bearings with high precision rails on every axis give less rolling moment resistance which translates to more torque from the motors.
| Structure: | |
|---|---|
| Cutting Area: | |
| Working Table: | |
| Spindle: | |
UT-1325
UTECH
1325 CNC Router For Wood Door KT-board Cnc Machine Plywood Carving Cutting Machine
One wood box: 2/3 sets SESAME 1325
One container: 6 sets SESAME 1325
The SESAME CNC Router is a cost-effective and feature-rich CNC Router that opens many avenues for your business. The SESAME CNC Series is constructed with a heavy-duty thickened bed made from welded 200*300mm square tube, aside from hanging structure, heavy-duty column, and 150*200mm gantry. Industrial quality linear bearings with high precision rails on every axis give less rolling moment resistance which translates to more torque from the motors.
The SESAME CNC Series CNC router comes equipped with a 4.5kw Air-cooled spindle, ER25 collets, which much suitable for basic advertising and the woodworking industry. This machine is equipped with a handle controller, doesn't need to connect with a computer, the interface is simple and easy to operate, if you’re an entry-level user, it would be a good choice. The machine is equipped with a reducer structure, compared with the characteristics of the looseness, short life, and insignificant deceleration effect of the gear box and timing belt, the reducer has the advantages of low backlash, low noise, high strength, and accurate deceleration effect.
It's assembled by UTECH professional assembly team’s precision meter assembly to ensure that the repeat positioning accuracy is ±0.01mm, and the accuracy of returning to the machine origin is ±0.02mm.
The aluminum alloy T-shaped table is equipped with a patented clamping fixture, which is convenient for customers to disassemble and assemble materials. Optional vacuum adsorption table. If choose vacuum adsorption table, will be matched with T-slot table together, the adsorption table is made of A-grade hard PVC board to prevent deformation.
This ensures the table holds a strong suction and tight tolerances for precision cutting. The machine also can be equipped with a pneumatic roller. This attachment will effectively prevent materials from moving during the cut. For machining thin or small sheet materials that are not easily vacuumed.
SESAME CNC Router's Parameters:
| Model | UT-1325/UT-1530/UT-1632/UT-2131/UT-2141 |
| Accuracy | ±0.02mm |
| Table Surface | Vacuum/T-slot table OR Double table |
| Frame | Square pipe welding bed structure 200*300mm+150*200mm gantry |
| X, Y Structure | 1.25M Helical gear rack transmission, Taiwan Linear Rail Guide |
| Z Structure | Taiwan TBI Ball Screw, Taiwan Linear Rail Guide |
| Spindle Power | 4.5kw air cooled spindle+ER25 cutter |
| Spindle Speed | 18000-24000RPM |
| Drive Motors | JMC stepper motor and driver+UTECH patent typre reducer |
| Operating System | HD100 handle controller (DSP or Mach3 optional) |
| Dust Collector | 2.2kw/3kw/5.5kw/7.5kw |
| Software | Vectric Aspire/Type 3 /Artcam /Ucancam/JDPaint |
Why Choose US?
The greatest advantage of the SESAME CNC engraving machine is its detachable bed and legs, allowing for shipping as needed, saving space and transportation costs. A 20GP container can hold six SESAME 1325 machines, while a 40HQ container can hold 20.
Each machine undergoes rigorous testing before shipment. Only machines that meet these standards are shipped, ensuring you receive a flawless, ready-to-use machine. We also offer local service in countries such as the United States, Mexico, Peru, France, Spain, and Romania.
Applicable Industry
About Us
Packing&Delivery
Packing:
1/ If the machine is delivered via LCL, then would be packed with wrapping film, EPE foam, and a standard export plywood box.
2/ If machine delivery via FCL, then don't need a wood box, would be packed with wrapping film and EPE foam.
Shipping:
We support machine delivery via express, air transportation, land transportation, and sea transportation.
1/ Such as some small machine, Mini CNC Router or Small CO2 Laser Machine and Fiber Laser Marking Machine, usually delivered via express and air transportation.
2/ If you wanna us to help you deliver to a domestic warehouse or Russia, Kazakhstan, etc, usually delivered via land transportation.
3/ Large machines or some countries where shipping is more convenient, usually suggest choosing sea transportation.
You can choose any way you'd prefer, we also will give you some proper suggestions.
