Portable Co2 Laser Cutter Engraving Cutting Machine For Acrylic Fabric Cloth

The machine is equipped with user-friendly interface and software, making operation simple and easy to understand.
Working Table:
Laser power:
Laser control system:
Driving System:
Minimum letter size:
  • CO2


  • CO2

High precision CO2 laser engraving cutting machine

The Portable Co2 Laser Cutter Engraving Cutting Machine For Acrylic Fabric Cloth is an advanced cutting equipment that uses high-energy laser beams to precisely cut materials into the desired shape. This machine combines high-tech laser technology with advanced control systems to meet a variety of industrial cutting needs. UTECH Portable Co2 Laser Cutter Engraving Cutting Machine For Acrylic Fabric Cloth can achieve very high cutting accuracy and can cut workpieces with complex shapes, fine details, and precise dimensions, reducing waste.And it has fast cutting speed, which can improve production efficiency and shorten processing cycle. Carbon dioxide laser cutting machine is a non-contact processing technology that does not cause physical deformation or damage to materials and is suitable for applications that require high material quality and appearance. The machine can cut and engrave Chinese and English characters, numbers, trademarks and other vector graphics, serial numbers, batch numbers, specifications and other product labels on the surface of non-metallic materials, and can cut many different types of materials, including metals and non-metals, such as steel. , stainless steel, aluminum, plastic, leather, cloth, etc. UTECH Portable Co2 Laser Cutter Engraving Cutting Machine For Acrylic Fabric Cloth provides efficient, precise and versatile cutting solutions for manufacturing and other fields with its high precision, high efficiency, multi-material processing capabilities and wide range of application fields.

Machine Features

1/ DSP offline control system and USB interface. Software support Windows XP, Windows 7, 7, 8,10 compatible with artcut, CorelDraw, Photoshop, Auto CAD, etc.

2/ Front & Rear entry for the super-long plate to pass through.

3/ Safety Magnetic switch to make sure safety during work.

4/ Imported Linear rail guide with high durability, stability, precision.

5/ Waste collect device, easy to pick up samples and save raw materials.

6/ Most advanced double limit switches protect on XYZ axis, preventing the bump of laser parts.

co2 laser cutting machine detailsMulti Functions CO2 laser cutting machine working for Metal and Non Metal sheet materiales laser cut.

Cutting 30mm thickness for acrylic,25mm for plywood and others non metalerials
Cutting 1.2mm Stainless steel and 1.7mm carbon steel by 180Watts

Cutting 2.7mm Stainless steel and 2mm carbon steel by 280Watts.

Main Parts:

1. Grey white
2. RUIDA RDC644G controller
3. Laser tube Beijing RECI Laser Tube
4. Imported II-VI Mirrors and Lens
5. Imported Taiwan PMI  linger guide and block
6. Leadshine driver and motor
7. Bedi belt/Germany ONK
8. power supply with meter
9. Knife working table
10. Power control for chiller, Fan, air pump
11. Air pump ACO-009D 135W
12. Exhaust fans 550W
13. Standard Teyu cooling system
14. Toolbox  (Includes USB flash drive, software, installation video, manual, focusing gauge, dimming board, power cord, cotton swab, wrench, steel ruler, screwdriver, paper tape, high-pressure tape, etc)
15. Standard wooden case package


Optional parts:


1) Honeycomb working table
2) Motorized up and down table
3) Autofocus
4) Red dot positioning
5) Rotary
6) Other brand laser tube


1390 Laser engraving machine
Working area
1300*900mm (Can tailor-made for you)
Laser power
Reci 80w/100w/130w/150w
Laser tube type
Sealed CO2 glass laser tube
laser tube cooling type
S&A Industrial Water Chiller
Cutting speed
Repositioning accuracy
Working voltage
AC110v/220v 50Hz/60Hz
Consuming power
Laser control system
RDC6442S control system
Driving system
YAKO stepper motor YKD3505M-DK-B1 and driver YK368-826G
Working table
Blade table ( Alternative Honeycomb table )
Linear guide
ABBA square rail (sub-brand of SKF)
Minimum letter size
English:1mm x1mm; Chinese: 2mm x 2mm


1. Mainly used for engraving and cutting large-scale blister characters, two-color plate engraving, PMMA organic glass engraving and cutting, nameplate crystal trophies and other authorization cards.

2. Handicraft industry: carving various patterns and characters on wood, bamboo, ivory, bone, leather, marble, shells, etc.

3. Leather and clothing processing industry: used for engraving, cutting and hollowing out complex text and graphics on genuine leather, synthetic leather, artificial leather, fabric and fur. Such as clothing, clothing, underwear, furniture, gloves, handbags, shoes and hats, toys, car decoration and other industries. Make them transcend fashion and stand out.

4. Model industry: making sand table architectural models, aircraft models, ABS board cutting, and multi-layer cutting.

5. Packaging industry: engraving and printing rubber sheets, plastic sheets, double-layer, knife-cut boards.

6. Product identification industry: equipment nameplates, product anti-counterfeiting labels, advertising and logo production, can cut various advertising signs, logos, signs, etc.

7. Other industries: engraving and marking of marble, granite, glass, crystal and other decorative materials, cutting and processing of paper crafts such as paper and greeting cards.

Advertising and signage production: Can cut all kinds of advertising signs, logos, signage, etc.

co2 laser cutting machine application
