UTECH SESAME Series CNC plasma cutter is a high-efficiency, high-precision, and high-reliability cutting device integrating computer control, precision mechanical transmission, and thermal cutting. A good man-machine interface makes the operation more convenient and simple and can cut quickly and accurately. A variety of complex shapes of plates, especially suitable for medium and thin non-ferrous metal sheets, stainless steel, and carbon steel sheet automatic cutting, it adopts integrated modular design, quick installation, and is easy to move.
| Working Table Size: | |
|---|---|
| Motor and driver: | |
| Table: | |
| Power Source: | |
| Certification: | |
SESAME P1
UTECH CNC Plasma Cutting Machine
UTECH CNC Plasma Cutting Machine's characteristics:
Not easy to deform, durable: The machine adopts a thickened steel plate welded body structure, which is processed by special technology to ensure that the whole machine is rigid and never deforms, achieves ultra-high cutting accuracy, and has an ultra-long service life.
Precision guide, stable and reliable: Equipped with Taiwan's high-precision linear guide rails, it effectively guarantees the accuracy of the vertical section during the cutting process, and the cutting quality is even better.
Software compatibility, convenient operation: Perfectly compatible with mainstream cutting software, such as Artcam/Fastcam/Starfire, etc.
Intelligent cutting, precise follow-up: Equipped with a high-performance cutting system (optional: Beijing Starfire/Start/FLMC-2300A or DSP), and standard automatic height controller (THC). It can intelligently sense the surface fluctuations of the material, and automatically, quickly and stably adjust the cutting height in real time to ensure consistent cutting quality.
Thick material worry-free, environmentally friendly cutting: For the needs of thick plate cutting, we can add a special water tank for free (according to the actual working conditions) to effectively absorb the large amount of smoke generated by cutting and improve the working environment.
Deep customization, exclusive solutions: We know that your needs may be different. No matter what special requirements you have for machine specifications or appearance design, we can provide tailor-made solutions. Please feel free to let us know your needs!
Model | SESAME P1 CNC Cutting Machine |
Working size | 1500mm*3000mm, 100mm stroke z-axis sliding table |
Cutting speed | 10-15m/min |
Transmission system | 1.25m rack, square 20 linear guide and slider |
Operating System | Starfire SF2100/DSP A12 control system |
Driver | JMC stepper motor and driver |
Plasma power supply | Huayuan/Hypertherm |
Cutting thickness | 0-30mm |
Cutting type | Plasma/oxy-acetylene or propane |
Input voltage | 3 phase, 220v/380v±10% |
Mode of file transfer | USB Interface |
Water tank | Underlay stainless steel sink(absorb smoke and prevent burning) |
Table-board | sawtooth + square pipe, spacing is 70 mm |
Straight line positioning precision | ±0.2mm/10m |
Straight line repeat precision | ±0.3mm/10m |
Environmental temperature | -5~45°C |
Humidity | <90% No concreting |
UTECH CNC Plasma Cutting Machine
UTECH CNC Plasma Cutting Machine's characteristics:
Not easy to deform, durable: The machine adopts a thickened steel plate welded body structure, which is processed by special technology to ensure that the whole machine is rigid and never deforms, achieves ultra-high cutting accuracy, and has an ultra-long service life.
Precision guide, stable and reliable: Equipped with Taiwan's high-precision linear guide rails, it effectively guarantees the accuracy of the vertical section during the cutting process, and the cutting quality is even better.
Software compatibility, convenient operation: Perfectly compatible with mainstream cutting software, such as Artcam/Fastcam/Starfire, etc.
Intelligent cutting, precise follow-up: Equipped with a high-performance cutting system (optional: Beijing Starfire/Start/FLMC-2300A or DSP), and standard automatic height controller (THC). It can intelligently sense the surface fluctuations of the material, and automatically, quickly and stably adjust the cutting height in real time to ensure consistent cutting quality.
Thick material worry-free, environmentally friendly cutting: For the needs of thick plate cutting, we can add a special water tank for free (according to the actual working conditions) to effectively absorb the large amount of smoke generated by cutting and improve the working environment.
Deep customization, exclusive solutions: We know that your needs may be different. No matter what special requirements you have for machine specifications or appearance design, we can provide tailor-made solutions. Please feel free to let us know your needs!
Model | SESAME P1 CNC Cutting Machine |
Working size | 1500mm*3000mm, 100mm stroke z-axis sliding table |
Cutting speed | 10-15m/min |
Transmission system | 1.25m rack, square 20 linear guide and slider |
Operating System | Starfire SF2100/DSP A12 control system |
Driver | JMC stepper motor and driver |
Plasma power supply | Huayuan/Hypertherm |
Cutting thickness | 0-30mm |
Cutting type | Plasma/oxy-acetylene or propane |
Input voltage | 3 phase, 220v/380v±10% |
Mode of file transfer | USB Interface |
Water tank | Underlay stainless steel sink(absorb smoke and prevent burning) |
Table-board | sawtooth + square pipe, spacing is 70 mm |
Straight line positioning precision | ±0.2mm/10m |
Straight line repeat precision | ±0.3mm/10m |
Environmental temperature | -5~45°C |
Humidity | <90% No concreting |
