The UTECH team has tested and implemented many loading and unloading solutions, such as 2/3 machines to pack a same wooden box; a 20GP container to package 6 sets SESAME 1325, a 40HQ container to package 20 sets SESAME 1325, etc.
| Structure: | |
|---|---|
| Cutting Area: | |
| Working Table: | |
| Spindle: | |
| Transmission: | |
SESAME U-1325
UTECH
UTECH SESAME Series CNC Router Machine
One wood box: 2/3 sets SESAME 1325
One container: 6 sets SESAME 1325
UTECH 1325 entry-level CNC woodworking engraving machine is a cost-effective equipment tailored for start-ups in the advertising, furniture and board processing industries. The whole machine adopts a standard processing area of 1300×2500mm, with a heavy-duty welded bed and an industrial-grade square tube gantry structure to ensure stability and durability under long-term operation. The standard 4.5kW high-performance air-cooled spindle can efficiently complete the engraving, cutting and grooving of materials such as wood, PVC, MDF, acrylic, etc. The machine is also equipped with a high-precision linear guide and ball screw transmission system, which significantly improves the processing accuracy and reduces the operating noise. The control system is easy to operate and can be used in a short time. The machine also supports upgrading the adsorption platform and dust removal system to meet various processing needs. It is an ideal entry-level equipment for advertising and logo factories, cabinet door panel manufacturers, small furniture factories and educational training institutions.
SESAME CNC Router's Parameters:
| Model | UT-1325/UT-1530/UT-1632/UT-2131/UT-2141 |
| Accuracy | ±0.02mm |
| Table Surface | Vacuum/T-slot table OR Double table |
| Frame | Square pipe welding bed structure 200*300mm+150*200mm gantry |
| X, Y Structure | 1.25M Helical gear rack transmission, Taiwan Linear Rail Guide |
| Z Structure | Taiwan TBI Ball Screw, Taiwan Linear Rail Guide |
| Spindle Power | 4.5kw air cooled spindle+ER25 cutter |
| Spindle Speed | 18000-24000RPM |
| Drive Motors | JMC stepper motor and driver+UTECH patent typre reducer |
| Operating System | HD100 handle controller (DSP or Mach3 optional) |
| Dust Collector | 2.2kw/3kw/5.5kw/7.5kw |
| Software | Vectric Aspire/Type 3 /Artcam /Ucancam/JDPaint |
Why Choose US?
The SESAME CNC Router’s greatest advantage is machine lathe bed and legs could be split freely, accoding to customer’s request, can choose to disassemble the machine when shipping, which could save space and shipping cost. In such a severe international situation, harsh conditions such as difficulty in booking space and rising freight rates have severely hindered the transportation of goods and the normal operation and development of enterprises. SESAME’s disassembly advange would be a shining point in the near future. The UTECH team has tested and implemented many loading and unloading solutions, such as 2/3 machines to pack a same wooden box; a 20GP container to package 6 sets SESAME 1325, a 40HQ container to package 20 sets SESAME 1325, etc.
Before the machine leaves the factory, each machine will undergo rigorous testing. You can leave the factory only after reaching the standard, and you will get a perfect device that can be used directly. And we provide local services, such as the United States, Mexico, Peru, France, Spain, Romania and other countries.
Applicable Industry
Company Information
Packing&Delivery
Packing:
1/ If the machine is delivered via LCL, then would be packed with wrapping film, EPE foam, and a standard export plywood box.
2/ If machine delivery via FCL, then don't need a wood box, would be packed with wrapping film and EPE foam.
Shipping:
We support machine delivery via express, air transportation, land transportation, and sea transportation.
1/ Such as some small machine, Mini CNC Router or Small CO2 Laser Machine and Fiber Laser Marking Machine, usually delivered via express and air transportation.
2/ If you wanna us to help you deliver to a domestic warehouse or Russia, Kazakhstan, etc, usually delivered via land transportation.
3/ Large machines or some countries where shipping is more convenient, usually suggest choosing sea transportation.
You can choose any way you'd prefer, we also will give you some proper suggestions.
UTECH SESAME Series CNC Router Machine
One wood box: 2/3 sets SESAME 1325
One container: 6 sets SESAME 1325
UTECH 1325 entry-level CNC woodworking engraving machine is a cost-effective equipment tailored for start-ups in the advertising, furniture and board processing industries. The whole machine adopts a standard processing area of 1300×2500mm, with a heavy-duty welded bed and an industrial-grade square tube gantry structure to ensure stability and durability under long-term operation. The standard 4.5kW high-performance air-cooled spindle can efficiently complete the engraving, cutting and grooving of materials such as wood, PVC, MDF, acrylic, etc. The machine is also equipped with a high-precision linear guide and ball screw transmission system, which significantly improves the processing accuracy and reduces the operating noise. The control system is easy to operate and can be used in a short time. The machine also supports upgrading the adsorption platform and dust removal system to meet various processing needs. It is an ideal entry-level equipment for advertising and logo factories, cabinet door panel manufacturers, small furniture factories and educational training institutions.
SESAME CNC Router's Parameters:
| Model | UT-1325/UT-1530/UT-1632/UT-2131/UT-2141 |
| Accuracy | ±0.02mm |
| Table Surface | Vacuum/T-slot table OR Double table |
| Frame | Square pipe welding bed structure 200*300mm+150*200mm gantry |
| X, Y Structure | 1.25M Helical gear rack transmission, Taiwan Linear Rail Guide |
| Z Structure | Taiwan TBI Ball Screw, Taiwan Linear Rail Guide |
| Spindle Power | 4.5kw air cooled spindle+ER25 cutter |
| Spindle Speed | 18000-24000RPM |
| Drive Motors | JMC stepper motor and driver+UTECH patent typre reducer |
| Operating System | HD100 handle controller (DSP or Mach3 optional) |
| Dust Collector | 2.2kw/3kw/5.5kw/7.5kw |
| Software | Vectric Aspire/Type 3 /Artcam /Ucancam/JDPaint |
Why Choose US?
The SESAME CNC Router’s greatest advantage is machine lathe bed and legs could be split freely, accoding to customer’s request, can choose to disassemble the machine when shipping, which could save space and shipping cost. In such a severe international situation, harsh conditions such as difficulty in booking space and rising freight rates have severely hindered the transportation of goods and the normal operation and development of enterprises. SESAME’s disassembly advange would be a shining point in the near future. The UTECH team has tested and implemented many loading and unloading solutions, such as 2/3 machines to pack a same wooden box; a 20GP container to package 6 sets SESAME 1325, a 40HQ container to package 20 sets SESAME 1325, etc.
Before the machine leaves the factory, each machine will undergo rigorous testing. You can leave the factory only after reaching the standard, and you will get a perfect device that can be used directly. And we provide local services, such as the United States, Mexico, Peru, France, Spain, Romania and other countries.
Applicable Industry
Company Information
Packing&Delivery
Packing:
1/ If the machine is delivered via LCL, then would be packed with wrapping film, EPE foam, and a standard export plywood box.
2/ If machine delivery via FCL, then don't need a wood box, would be packed with wrapping film and EPE foam.
Shipping:
We support machine delivery via express, air transportation, land transportation, and sea transportation.
1/ Such as some small machine, Mini CNC Router or Small CO2 Laser Machine and Fiber Laser Marking Machine, usually delivered via express and air transportation.
2/ If you wanna us to help you deliver to a domestic warehouse or Russia, Kazakhstan, etc, usually delivered via land transportation.
3/ Large machines or some countries where shipping is more convenient, usually suggest choosing sea transportation.
You can choose any way you'd prefer, we also will give you some proper suggestions.
