Fast Speed CNC Router Machine 1325 Wood Carving Machine

Fast Speed CNC Router Machine 1325 Wood Carving Machine

The SESAME CNC Router is a cost-effective and feature-rich CNC Router that opens many avenues for your business.

• Heavy-duty thickened bed made from welded 200*300mm square tube

• Side hanging structure

• Heavy-duty mechanical tool column

• 150*200mm gantry

• Industrial quality linear bearings

• Patent type reducer structure

• 4.5kw air cooled spindle+ER25 collect

• HD100 handle controller, easy operate

• The repeat positioning accuracy is ±0.01mm

• The accuracy of returning to the machine origin is ±0.02mm

• Aluminum alloy T-shaped table+Vacuum adsorption table

• Split structure of machine legs and lathe bed

• Industrial dust removal system

SESAME Series CNC Router Machine's Advantages

The SESAME CNC Router’s greatest advantage is machine lathe bed and legs could be split freely, according to the customer’s request, can choose to disassemble the machine when shipping, which could save space and shipping cost. In such a severe international situation, harsh conditions such as difficulty in booking space and rising freight rates have severely hindered the transportation of goods and the normal operation and development of enterprises. SESAME’s disassembly advantage would be a shining point in the near future. The UTECH team has tested and implemented many loading and unloading solutions, such as 2/3 machines to pack the same wooden box; a 20GP container to package 6 sets SESAME 1325, a 40HQ container to package 20 sets SESAME 1325, etc.

Before the machine leaves the factory, each machine will undergo rigorous testing. You can leave the factory only after reaching the standard, and you will get a perfect device that can be used directly. And we provide local services, such as the United States, Mexico, Peru, France, Spain, Romania, and other countries.

Product Parameter

Machine Detailed Pictures

Body Structure

Is constructed with the heavy-duty thickened bed made from welded 200*300mm square tube, aside from hanging structure, a cast iron column, and a 150*200mm gantry.

Machine Spindle

Equipped with 4.5kw air cooled spindle, use ER25 collect, can use 3.175, 4, 6, 8, 12.7, 16mm cutter, sufficient power 3.7kw, much suitable for simple woodworking industry.

Reducer Structure

Is equipped with a reducer structure, compared with the characteristics of the looseness, short life, and insignificant deceleration effect of the gearbox and timing belt, the reducer has the advantages of low backlash, low noise, high strength, and accurate deceleration effect.

Z axis Structure

Z-axis transmission parts adopt aviation aluminum alloy T6061/6063, which are all made by professional precision machining centers, with high precision.

Patent separable structure

The legs and body of SESAME CNC can be separated freely, save packing volume and shipping cost.

1. If you are an individual buyer: 2 sets/3 sets can be packed in a wooden box

2. If you're a dealer

• a 20GP container to package 6 sets SESAME 1325.

• a 40HQ container to package 20 sets SESAME 1325.

Easy to install the disassembly method and installation guide video so that you have no worries at home.

Position Forklift

Forklift loading and unloading reserved, which can better protect machine body and cargo's carrying capacity.

Machine Working Table

Vacuum table&T-slot table together, you can choose to use one of them according to which kind of material or size you wanna process. Updated structure, except standard diversion trench, with some drainage groove, increased airflow space, enhanced adsorption.

Applications

1. Advertising industry
Acrylic cutting, density board cutting, snowflake cutting, double color board carving, various advertising boards.
2. Furniture industry
Cabinet doors, wooden doors, solid wood, mahogany furniture, antique furniture, all kinds of composite sheet
cutting carving.
3. Plate processing industry
Insulation board, plastic workpiece, PCB board, anti-double board, epoxy resin, ABS, PP, PE, and other carbon mixtures.
4. Crafts industry
Artificial marble, PVC, wood, plexiglass, copper aluminum, and so on.
