UTECH SESAME Series CNC plasma cutter is a high-efficiency, high-precision, and high-reliability cutting device integrating computer control, precision mechanical transmission, and thermal cutting. A good man-machine interface makes the operation more convenient and simple and can cut quickly and accurately. A variety of complex shapes of plates, especially suitable for medium and thin non-ferrous metal sheets, stainless steel, and carbon steel sheet automatic cutting, it adopts integrated modular design, quick installation, and is easy to move.
| Working Table Size: | |
|---|---|
| Motor and driver: | |
| Table: | |
| Power Source: | |
| Certification: | |
SESAME P1
UTECH CNC Plasma Cutting Machine
This CNC plasma cutting machine adopts a high-strength thickened steel structure bed. The whole machine has undergone professional heat treatment and stress relief process to effectively prevent deformation and ensure that the equipment still maintains excellent cutting accuracy and stability during long-term continuous operation. Equipped with a linear guide system imported from Taiwan, it has smooth movement and ensures that the vertical cutting surface is neat and beautiful, which is particularly suitable for metal processing tasks with high cutting quality requirements. The whole machine is compatible with a variety of stable and reliable control systems, including Beijing Starfire system/ Start system/ FLMC-2300A or DSP system, and is equipped with an arc voltage automatic height adjustment (THC) control system as standard. It can intelligently adjust the height of the cutting nozzle according to the surface fluctuations of the metal plate, effectively avoiding cutting or hanging in the air, and ensuring the continuity and consistency of each cutting line.
In order to deal with the large amount of smoke and dust generated during the thick plate cutting process, the equipment can also be equipped with a water tank system (free configuration) according to demand, which significantly reduces the diffusion of smoke and improves the cleanliness and safety of the operating environment. The whole machine supports flexible customization, including effective working area, appearance structure, electrical configuration, etc. It is widely used in sheet metal processing, machinery and equipment manufacturing, steel structure engineering, metal component cutting and other industries. It is an ideal plasma cutting solution that integrates practicality, scalability and economy.
Model | SESAME P1 CNC Cutting Machine |
Working size | 1500mm*3000mm, 100mm stroke z-axis sliding table |
Cutting speed | 10-15m/min |
Transmission system | 1.25m rack, square 20 linear guide and slider |
Operating System | Starfire SF2100/DSP A12 control system |
Driver | JMC stepper motor and driver |
Plasma power supply | Huayuan/Hypertherm |
Cutting thickness | 0-30mm |
Cutting type | Plasma/oxy-acetylene or propane |
Input voltage | 3 phase, 220v/380v±10% |
Mode of file transfer | USB Interface |
Water tank | Underlay stainless steel sink(absorb smoke and prevent burning) |
Table-board | sawtooth + square pipe, spacing is 70 mm |
Straight line positioning precision | ±0.2mm/10m |
Straight line repeat precision | ±0.3mm/10m |
Environmental temperature | -5~45°C |
Humidity | <90% No concreting |
UTECH CNC Plasma Cutting Machine
This CNC plasma cutting machine adopts a high-strength thickened steel structure bed. The whole machine has undergone professional heat treatment and stress relief process to effectively prevent deformation and ensure that the equipment still maintains excellent cutting accuracy and stability during long-term continuous operation. Equipped with a linear guide system imported from Taiwan, it has smooth movement and ensures that the vertical cutting surface is neat and beautiful, which is particularly suitable for metal processing tasks with high cutting quality requirements. The whole machine is compatible with a variety of stable and reliable control systems, including Beijing Starfire system/ Start system/ FLMC-2300A or DSP system, and is equipped with an arc voltage automatic height adjustment (THC) control system as standard. It can intelligently adjust the height of the cutting nozzle according to the surface fluctuations of the metal plate, effectively avoiding cutting or hanging in the air, and ensuring the continuity and consistency of each cutting line.
In order to deal with the large amount of smoke and dust generated during the thick plate cutting process, the equipment can also be equipped with a water tank system (free configuration) according to demand, which significantly reduces the diffusion of smoke and improves the cleanliness and safety of the operating environment. The whole machine supports flexible customization, including effective working area, appearance structure, electrical configuration, etc. It is widely used in sheet metal processing, machinery and equipment manufacturing, steel structure engineering, metal component cutting and other industries. It is an ideal plasma cutting solution that integrates practicality, scalability and economy.
Model | SESAME P1 CNC Cutting Machine |
Working size | 1500mm*3000mm, 100mm stroke z-axis sliding table |
Cutting speed | 10-15m/min |
Transmission system | 1.25m rack, square 20 linear guide and slider |
Operating System | Starfire SF2100/DSP A12 control system |
Driver | JMC stepper motor and driver |
Plasma power supply | Huayuan/Hypertherm |
Cutting thickness | 0-30mm |
Cutting type | Plasma/oxy-acetylene or propane |
Input voltage | 3 phase, 220v/380v±10% |
Mode of file transfer | USB Interface |
Water tank | Underlay stainless steel sink(absorb smoke and prevent burning) |
Table-board | sawtooth + square pipe, spacing is 70 mm |
Straight line positioning precision | ±0.2mm/10m |
Straight line repeat precision | ±0.3mm/10m |
Environmental temperature | -5~45°C |
Humidity | <90% No concreting |
