4*8FT Professional Oscillating Knife CNC Router For Wood Acrylic

Characteristics:

1. The bed is made of high-rigidity rectangular steel pipe welded and optimized dragnet structure, aging treatment to ensure the precision of the bed.

2. Double heads device--spindle and oscillating knife, can be cut according to different materials.  After many improved tests, we update machine, now machine only have one Z axis for spindle and oscillating knife, it’s integrated together to share one z-axis motor&drive, and doesn’t need another set of motor&driver to control the z-axis of oscillating knife separately.

3. Excellent visual positioning system, one-click cutout and one-click start processing, free of typesetting&cutout time, improve processing efficiency. Equipped with professional 1.5 megapixel industrial camera, powerful image recognition, more accurate cutting.

4. Oscillating knife head can be processed and tracing-edge cutting according to different materials, the material dust-free and without raw edge.

5. CCD: Tracing-edge cutting for different materials, KT board, PVC, photo paper to achieve no burr cutting.

6. Transmission model adopt precision reducer match with brand gear rack, large torque, low noise and high transmission precision accuracy.

7. Machine supports DXF, JPG, PNG, NC and other formats, not only with automatic tracing-edge, but also support the function of CNC router.

Application:

4*8FT Professional Wood Acrylic Oscillating Knife CNC Router Common cutting applications/materials

1. Woodworking industry: Very suitable for furniture decoration, musical instruments, wooden handicrafts, solid wood furniture, medium density fiberboard paint-free doors, solid wood composite doors, cabinets, kitchen doors, windows, bedside tables, etc.

2. Decoration industry: art models, wall art, screen relief and cutting, decorative processing, gift packaging, corrugated boards, electrical cabinet panels, sports equipment and other wooden industrial products.

3. Advertising: acrylic, two-color board, PVC, ABS board, aluminum board, density board, artificial stone, organic glass, aluminum, copper and other soft metals, cutting matrix, text, signs, trademarks.

4. Composite soft materials such as glass fiber, glass fiber wool, prepreg, carbon fiber, carbon fiber felt, boron fiber, aramid fiber, ceramic fiber, soft glass, PVC, leather, artificial leather, silicone, rubber materials.

Machine with oscillating knife, CCD visual positioning system and cnc spindle. Except EOT-3 oscillating knife for cutting many kinds of soft materials, CCD visual positioning system with automatic tracing-edge, also support the function of CNC router.

Configurations:

1/ EOT-3 - Oscillating Tangential Knife

The EOT-3 is a processing unit for CNC-machines to cut various materials such as cardboard, sealing materials, foils, corrugated cardboard, carbon fiber prepreg material, leather, rigid foam and many others. A powerful oscillation motor moves the blade quickly up and down while an actuator rotates the blade in each direction of cutting. Thus, even strong and thick materials can be cut precisely and quickly.

 * CNC-machined, rugged metal housing

* Precision kinematics

* Oscillation frequency: approx. 3500 –7000 stroke per minute (12-20VDC)

* Drive motor with multiple ball bearings

* Opto-electronic, contactless detection of the blade position

* Equipped with a reverse polarity protection and an optical display for the working status

* Internal voltage regulator and stabilizer

* Equipped with a signal amplifier that generates a clearly defined digital signal for the reference position of the tangential axis.

* High compatibility with equipment from different manufacturers

 2/ UTECH-Knife V5.5.0 Visual Positioning Cutting&Engraving Control System

Multifunction controller with PCI card slot, could support oscillating knife, CCD camera and spindle.

 3/ CCD camera for tracing-edge

Equipped with professional 1.5 megapixel industrial camera, powerful image recognition, more accurate cutting.

 4/ Machine Base Frame

The base frame is fabricated from heavy-duty tubular steel that is welded, precision machined and stress relieved so that the foundation remains true and steady over the operational life of the machine.

 5/ Anodized Aluminum Spindle Fixing plate

The spindle is fixed on the high quality aviation aluminum T6061/6063 plate, and it is Anodized Aluminum processing, the plate is machined by high precision CNC machining center.

 6/ Dust cover for the guide rail and the helical rack gear

The machine is designed with the dust cover for the guide rail and the helical rack and gear, to reduce friction, make the rail and the rack have longer service life.

 7/ Japan SHIMPO 1:5/1:10 gear reducer + Servo motor&driver(Delta/YASKAWA/Panasonic)

Due to machine with servo motor&driver, then we install Japan SHIMPO 1:10 gear reducer on driving motor, makes the motor is more powerful, and having a longer time service life.

The servo motors are installed on all axis to ensure precise positioning of the gantry and the spindle in accordance with a predetermined program at high speed. Hybrid servo or Delta servo motors are well proven high degree of reliability.

 8/ Reserved Position for Forklift

Bed welding process increases the reserved forklift, highlights two major advantages: First, increase the strength of the bed itself; Second, it`s more convenient for customers to load or unload the equipment.

Packing:

1/ Machine packed with EPE foam, wrapping film and standard export plywood box.
